Overview
Seamless Hybrid Communication for the Modern Enterprise
Elevate your meeting infrastructure with our next-generation Wireless Conference System. Designed for ultimate flexibility and rock-solid stability, this system bridges the gap between traditional wired setups and modern wireless mobility. Utilizing high-performance Wireless Access Points (WAP), it eliminates the need for complex cabling, making it the perfect solution for historical renovations, flexible conference rooms, and rapid-response mobile meeting environments.
Product features
• Ultimate Redundancy
Featuring a sophisticated Digital-Analog hybrid backup architecture, the system supports DANTE/AES67 protocols for broad interoperability. Dual power redundancy ensures that your high-stakes meetings remain uninterrupted, even in the event of a power failure.
• Encrypted High-Fidelity Audio
Experience crystal-clear, transparent sound with a 96KHz sampling rate and ultra-low latency (<5ms). Every transmission is protected by advanced digital encryption and ID pairing, safeguarding your sensitive communications from unauthorized access.
• Intuitive Ecosystem Management
Manage up to four independent rooms from a single host. The system integrates effortlessly with existing wired networks and central control units, supporting automated camera tracking, attendance registration, and electronic voting.
• Rapid Deployment
Skip the technical headaches. With PoE (Power over Ethernet) technology and simplified one-button access, you can deploy a full-scale conference environment in minutes, not hours.
• IoT & Mobile Control
Take command with smart IoT integration. Manage your entire conference environment via a convenient mini-program—no bulky software installations required.
Technical Parameters
| Operating Range: | 30 meters |
| Sensitivity: | At a deviation of 25 kHz and an input of 6 dBV, S/N > 60 dB |
| Frequency Bandwidth: | 50 MHz |
| Maximum Deviation: | ±45 kHz |
| Overall Signal-to-Noise Ratio (S/N): | >105 dB |
| Total Harmonic Distortion (T.H.D.): | <0.7% @ 1 kHz |
| Overall Frequency Response: | 45 Hz - 18 kHz ±1 dB |
| Power Input: | PoE/DC 12V 1.5A |
| Maximum Power Consumption: | 10W |
| Sampling Rate: | 96 kHz |
| Dante: | 4 channels, plug-and-play, automatic device discovery |
| Routing Control: | Dante Controller |
| PoE Standard: | IEEE 802.3af, IEEE 802.3at |
| PoE: | 10BASE-T: Category 3, 4, 5 unshielded twisted pair (≤100 meters). 100BASE-TX: Category 5 or above unshielded twisted pair (≤100 meters) |
| Control Method: | WeChat Mini Program |
| Control Connection Method: | Bluetooth |
| Bluetooth Effective Range: | ≤15 meters |
| Weight: | 800g |
| Dimensions: | 220*220mm |
