Overview
This digital wired microphone is designed specifically for modern conference environments, combining stylish structure, high-quality audio, and intelligent control. The dual capacitor diaphragm, variable directivity, and advanced digital audio technology ensure clear and reliable sound pickup in any conference environment. The system supports dual backup, hot swapping, and priority chairman control, making it highly stable and flexible. It is integrated with a microphone with camera tracking function, achieving seamless coordination between voice and video, providing a professional and efficient solution for conferences.
Product features
Design & Structure
• Stylish and ergonomic design, simple to operate and user-friendly;
• Dual electret condenser capsule ensures bright, clear, and highly sensitive sound;
• Each Digital Wired Microphone unit is equipped with a 1.8m Cat6 cable, with options for hidden or rear wiring to keep the table neat;
Audio & Processing
• Full digital audio technology with high-performance CPU ensures faster processing and superior sound quality;
• Optional analog-digital dual backup guarantees system reliability for uninterrupted important meetings;
• Anti-mobile interference capsule with durable and stable connections;
Pickup & Directionality
• Digital variable directivity technology allows adjustment to different environments and speaker needs;
• Supports five pickup patterns: omnidirectional, wide cardioid, cardioid, super cardioid, and figure-8;
• Two microphone activation modes: toggle switch or press-and-hold;
Meeting Control
• Chairman unit has priority control over meeting order, with no connection limitations;
• Delegate unit can be configured as VIP, free from activation restrictions;
• Chairman can approve delegate speaking requests quickly in application mode;
Video Integration
• Compatible with Microphone with Camera Tracking host system;
• Enables automatic camera tracking through computer presets, achieving smooth audio-video integration;
Speaking Modes & Indicators
• Supports five speaking modes: Normal, FIFO, Free, Application, and Voice-activated;
• Voice-activated mode allows adjustable sensitivity and automatic mute timing;
• Dual-color LED indicator shows speaking status (red when active);
Additional Features
• Equipped with a Ø3.5mm stereo headphone jack for earphone use;
• Each conference unit has a unique serial number for manual ID assignment;
• Supports hot-plugging to add more microphones anytime without interrupting system operation;
Technical Parameters
| Power Supply: | DC24V (host power supply) |
| Connection: | CAT6E Ethernet cable |
| Power Consumption: | 1.5W |
| Polar Patterns: | Omnidirectional, pancentric, cardioid, super cardioid, figure 8 |
| Microphone Type: | Condenser |
| Distortion: | <1% |
| Frequency Response: | 40Hz-20KHz |
| Switching Method: | Mechanical Switch |
| Sensitivity: | -32dBV |
| Dimensions: | Base: 180*142*59mm; Pole: 224*39*27mm |
| Weight: | 1210g |
Q&A
Q1: How do you ensure products meet the quality standards of my market?
① Certified Foundations: All products comply with ISO9001, BSCI, RoHS, FCC, and other certifications (specific certificate numbers available upon request).
② Market-Specific Adaptation: We facilitate third-party inspections, factory audits, and assist with certifications required for the target market (such as CE, FCC, etc.).
Q2: How do you handle sudden surges in orders without causing delays?
✓ 24-Hour Contingency Plan: Production line scheduling simulations and material alerts are finalized within 24 hours of order confirmation.
✓ Real-Time Production Tracking: Access live updates via our ERP system (remote video factory audits are available).
Q3: What is the process for customizing product specifications?
• 24-Hour Solution Design: Receive a feasibility report for conferencing systems within 24 hours.
